DC OUTPUT
|
|
|
Output Volts (V)
|
Output Amps (A)
|
|
GPR-1850HD
|
0 ~ 18
|
0 ~ 50
|
|
GPR-3520HD
|
0 ~ 35
|
0 ~ 20
|
|
GPR-6015HD
|
0 ~ 60
|
0 ~ 15
|
|
GPR-7510HD
|
0 ~ 75
|
0 ~ 10
|
|
GPR-16H50D
|
0 ~ 160
|
0 ~ 5
|
|
GPR-25H30D
|
0 ~ 250
|
0 ~ 3
|
|
GPR-35H20D
|
0 ~ 350
|
0 ~ 2
|
|
GPR-50H15D
|
0 ~ 500
|
0 ~ 1.5
|
|
GPR-60H15D
|
0 ~ 600
|
0 ~ 1.5
|
|
GPR-100H05D
|
0 ~ 1000
|
0 ~ 0.5
|
|
CONSTANT VOLTAGE OPERATION
|
|
Regulation
|
Line regulation ≦ 0.01% + 3mV
Load regulation ≦ 0.01% + 5mV (<10A)
Load regulation ≦ 0.02% + 5mV (≧10A)
|
|
Ripple & Noise
|
≦ 2mVrms (5Hz ~ 1MHz)
|
|
Recovery Time
|
≦ 100μS ( 50% Load change, Minimum load 0.5A )
|
|
Output range
|
0 to rating voltage continuously adjustable
|
|
CONSTANT CURRENT OPERATION
|
|
Regulation
|
Line regulation ≦ 0.2% + 3mA
Load regulation ≦ 0.2% + 3mA
|
|
Ripple Current
|
≦ 5mArms (≦ 20A)
≦ 20mArms (≦ 50A)
≦ 100mArms (≦ 100A)
|
|
Output Range
|
0 to rating current continuously adjustable
|
|
METER
|
|
Type
|
3 1/2 Digits 0.5" LED Display
|
|
Accuracy
|
± ( 0.5% of rdg + 2 digits )
|
|
INSULATION
|
|
Chassis and Terminal
|
100MΩ or above (DC 1000V)
|
|
Chassis and AC Cord
|
100MΩ or above (DC 1000V)
|
|
POWER SOURCE
|
|
|
|
AC120V±10%, 50/60Hz
( AC 220V or 240V order made)
|
|
ACCESSORIES
|
|
|
User manual x 1
Test lead GTL-105 x 1 (≦3A), or
GTL-104 x 1 (≦10A), or
Not available (>10A or 600V)
|
|
DIMENSIONS & WEIGHT
|
|
|
|
430(W) x 178(H) x 572(D)mm
Approx. 29.5kg
|
